MY23 CAMPER TRAILER
X1-H®
The X1-H features a remote controlled, hard top lid with a integrated solar panel on the lid for set up in full sun, away from shady campsites. Inside you’ll find a luxurious living quarters where strip lighting illuminates around the bed and three different tent configuration offers accommodation flexibility when you need it most.
AUD $59,790*
USD $48,400*
*PRICING DISPLAYED IS THE FROM PRICE. COST MAY VARY DUE TO OPTIONAL INCLUSIONS.
VIEW COLOUR OPTIONS
SLEEPS
SLEEPS 2-8
WITH OPTIONS
KG DRY TARE
2193LBS DRY TARE
BASE MODEL WITHOUT OPTIONS
KG ATM
3500LBS ATM
KG DRAW BAR
265LB DRAW BAR
LITRES STORAGE
70FT³ STORAGE
watch the comparison film
TOP X1-H FEATURES
TOP X1-H FEATURES
POWERED HARD LID SYSTEM
SETUP IN SECONDS
The X1-H features a remote controlled, hard top lid with a integrated solar panel that takes in sun on the road, with the ability to be set up in full sun when you set up camp in shade.
Once at camp, pop the latches on the hard top and use the remote control or the switch on the main control panel to set up your main tent in seconds.
- Set up using the remote or the control panel
- Fixed 120 Watt Solar Panel
- Zip on the change room and/or kids room for more space
CHASSIS AND SUSPENSION
GET OFF ROAD
The X1-H has been designed to go tackle any terrain, so you can visit the most off-the grid destinations. Experience the benchmark in offroad touring capability, with the X1-H’s many features, inspired by generations of Aussie adventurers.
- Choose between X-Cruise Coil Dual Shock Suspension or X-Cruise Air Bag Suspension (Tech Pack)
- Rigilite™ Chassis
- Maxtrek Tyres
- Rear Recovery Points
- 10″ Electric Drum Brakes
- 40º Departure Angle
CHASSIS AND SUSPENSION
GET OFF ROAD
The X1-H has been designed to go tackle any terrain, so you can visit the most off-the grid destinations. Experience the benchmark in offroad touring capability, with the X1-H’s many features, inspired by generations of Aussie adventurers.
- Choose between X-Cruise Coil Dual Shock Suspension or X-Cruise Air Bag Suspension (Tech Pack)
- Rigilite™ Chassis
- Maxtrek Tyres
- Rear Recovery Points
- 10″ Electric Drum Brakes
- 40º Departure Angle
3-STAGE CS3 TENT
camp in comfort
It’s not until you’ve climbed onto the X1-H’s gel-topped, pocket-spring mattress that you realise how comfortable the living quarters of this model is. Strip lighting illuminates the bed from the edges and ample head room makes the tent inside feels more spacious than ever. Some of the other features of the X1-H include:
- Sleeps between 2-8 People
- Gel-topped, pocket-spring mattress
- Tentstep Staircase
- Change Room
- Kids Room (Option)
ELECTRICAL SYSTEMS
SELF SUSTAIN
The X1-H is designed to go anywhere and stay there longer. A full electrical management system keeps your trailer and your gear charged and operational for weeks at a time.
With the Tech Pack optioned, you can enjoy:
- Redarc RedVision TVMS Upgrade
- X-Cruise 1.60T Air Bag Suspension & On-board Air Compressor
- Redarc 1000W Pure Sinewave Inverter
ELECTRICAL SYSTEMS
SELF SUSTAIN
The X1-H is designed to go anywhere and stay there longer. A full electrical management system keeps your trailer and your gear charged and operational for weeks at a time.
With the Tech Pack optioned, you can enjoy:
- Redarc RedVision TVMS Upgrade
- X-Cruise 1.60T Air Bag Suspension & On-board Air Compressor
- Redarc 1000W Pure Sinewave Inverter
TAKE THE TOUR
X1-H TECH SPECS
DIMENSIONS & WEIGHTS
TOTAL LENGTH: 3.75M (12FT)
TOTAL HEIGHT: 1.90M (6FT)
TOTAL WIDTH: 1.85M (6FT)
DEPARTURE ANGLE: 40°
995KG DRY TARE WEIGHT (2193LBS)
1600KG ATM (3527LBS)
2000L STORAGE (70FT³)
120KG DRAW BAR WEIGHT (264LBS)
WATCH OUR X1-H VIDEOS
FEATURES SUMMARY
The following options and features are included in the build as standard:
- Laser Cut Decals
- PCOR® Air Filter Cartridge
- Strong & Rugged Anderson Plug Design
- Awning Support Cradles
- 120 Watt Fixed Redarc Solar Panel
- Powered Composite Hard Lid
- Redarc TheManager30 with Switch Panel
- Rear Drawer incl. 6 Dividers
- Twin Burn Gas Stove & Grill
- Gas Hot Water Service
- Awning with Gas Assisted Lift
- 155L Water Tank Capacity*
- 2 x AGM or Gel Batteries
- X-Cruise Coil 1.60T Dual Shock Suspension
- CS3™ Integrated Tent With Change Room
- Standard 6/139.7 Stud Pattern
- 10″ Electric Drum Brakes
- 16” Wheels – ET0 & 33” Mud Terrain Tyres (x3)
- Spare Fullsize Wheel/Tyre and Rear Swingaway
- Green or White standard colours
*Water Tank Capacity may vary
The following options and features can be added to your build:
- Redarc RedVision TVMS Upgrade
- X-Cruise 1.60T Air Bag Suspension
- Redarc 1000W Pure Sinewave Inverter
The following options and features can be added to your build:
- Additional Gas Bottle Holder 4.5kg
- Tent Awning Sail kit (Set of 2)
- Utility Shelf Front Box
- Kids Room 2.2m Wide, 1.6m Long, 2.2m High, Grey
The following options and features can be added to your build:
- Dometic 55L Fridge/Freezer With Wifi, Ice Maker, Tie Down Straps & Anderson
- BBQ Swing Away Assembly
- Weber Baby Q (With 4 Tie Down Straps)
- X1 Wind Break Wall Kit (6 pcs)
- Power Adaptor, 15AMP To 10AMP, AMP-Fibian
The following options are are available for your camper trailer:
- Colour change to Graphite / Blue
- Extended Drawbar 200mm
- 2x Lithium Battery Upgrade
- GME XRS-330CTP W/6.6dBi Antenna & Foldable Mount
- Diesel Hot Water & Tent Heating System (replaces gas unit)
- BBQ Swing Away
- Jeep 5/127 Stud Pattern Change – ET+25
- LandCruiser 5/150 Stud Pattern Change – ET0
- Utility Slide Out, Right Hand Slide
- Additional Gas Bottle Holder 4.5kg
- X1 Front Box Utility Shelf
- Maxtrax Front Box Mounted
The following accessories are are available for your camper trailer:
- X1-H Tent Awning Sail Kit A (Drawbar Side)
- X1-H Tent Awning Sail Kit B (Tail-gate Side)
- X1 PCOR, Wind Break Wall, Kit (6pcs)
- X1-H Kids Room 2.2m Wide, 1.6m Long, 2.2m High, Grey
- Webber Baby Q (With 4 Tiedown Straps)
- Fridge/Freezer 53L with Wifi & Ice Maker, Dometic inc Tie Down & Anderson
- Fridge/Freezer 60L, Evakool Patriot Spec, Danfoss inc Tie Down & Anderson
- Power Adaptor, 15AMP to 10AMP, AMP-Fibian
- FUSION SteroActive Bluetooth Speaker
- Redarc Sun Power 150W With 10m Lead
- Redarc Sun Power 190W With 10m Lead
- X1 Wind Break Wall Kit (6 pcs)
STANDARD FEATURES
DECALS
Laser Cut Decals
– STANDARD –
PCOR® AIR FILTER
Improved Air Flow to Compartments
– STANDARD –
RUGGED CONNECTION
Stronger Anderson Plug Design
– STANDARD –
FRONT BOX UPDATE
Complete ergonomic redesign
– STANDARD –
SOLAR PANEL
120 Watt Redarc Solar Panel
– STANDARD –
Powered Hard Lid
Powered Composite
– STANDARD –
REDARC MANAGER 30
240V Battery Management System
– STANDARD –
REAR DRAWER
Large drawer with 6 dividers
– STANDARD –
TWIN BURNER STOVE
DOMETIC
– STANDARD –
GAS HOT WATER
Gas hot water system
– STANDARD –
PCOR® AWNING
With gas assisted lift
– STANDARD –
155L WATER TANK*
With Water Filler
– STANDARD –
TWIN BATTERIES
AGM or Gel Batteries
– STANDARD –
X-CRUISE SUSPENSION
X-Cruise Coil Suspension
– STANDARD –
CS3™ TENT
Quick setup integrated tent
– STANDARD –
PCOR WHEELS
16×9″ PCOR Wheels
– STANDARD –
SPARE WHEEL & TYRE
Rear SwingAway
– STANDARD –
STANDARD COLOURS
Green or White
– STANDARD –
rear recovery points
Recovery Points
– STANDARD –
GAS BOTTLE HOOK
Convenient Gas Bottle Hook
– STANDARD –
TECH PACK
REDVISION TVMS
Redarc Battery Management System
– TECH PACK –
AIR BAG SUSPENSION
X-Cruise 1.60 Susspension
– TECH PACK –
1000W INVERTER
Power Small Appliances
– TECH PACK –
Lifestyle pack
GAS BOTTLE HOLDER
Additional Gas Bottle Holder 4.5kg
– LIFESTYLE PACK –
Tent Awning Sail Kit
Extra Shade
– LIFESTYLE PACK –
UTILITY SHELF
Utility Storage
– LIFESTYLE PACK –
KIDS ROOM
Add-on room
– LIFESTYLE PACK –
THE ESSENTIALS PACK*
*ESSENTIALS PACK MUST BE PURCHASED WITH A TRAILER ORDER AND WILL BE FITTED TO THE TRAILER
DOMETIC 55L FRIDGE
Dometic CFX355IM 55L Fridge
– ESSENTIALS PACK –
SWING AWAY + BABY Q
Platform swings from front box
– ESSENTIALS PACK –
AWNING WALLS KIT
Wind Protection
– ESSENTIALS PACK –
AMP Fibian
15AMP to 10AMP Adaptor
– ESSENTIALS PACK –
OPTIONS
COLOUR CHANGE
Blue or Graphite
– OPTION –
EXTENDED DRAWBAR
Suits cars with rear spare
– OPTION –
LITHIUM UPGRADE
Upgrade both batteries to lithium
– OPTION –
GME XRS-330CTP
With 6.6dBi Antenna & Mount
– OPTION –
DIESEL HEATER
Water and tent heating
– OPTION –
BBQ SWINGAWAY
Platform swings from front box
– OPTION –
STUD PATTERN MATCH
LandCruiser 5/150 ET0 Change
– OPTION –
Utility slide out
Right hand side
– OPTION –
Additional GAS
Additional Gas Bottle Storage
– OPTION –
UTILITY SHELF
Located in the Front Box
– OPTION –
PCOR MAXTRAX
Front Box Mounted
– OPTION –
ACCESSORIES
Tent awning sail kit
Draw bar Side
– ACCESSORY –
Tent Awning Sail Kit
Tail Gate Side
– ACCESSORY –
WIND BREAK WALL Kit
6 Piece Kit
– ACCESSORY –
KIDS ROOM
Single pole add-on room
– ACCESSORY –
WEBER BABY Q
Q1000AU (With 4 Tie Down Straps)
– ACCESSORY –
DOMETIC FRIDGE
Dometic CFX355IM 55L Fridge
– ACCESSORY –
EVAKOOL FRIDGE
Patriot Spec EvaKool 60L Fridge
– ACCESSORY –
AMP FIBIAN
15AMP to 10AMP Adaptor
– ACCESSORY –
160W SOLAR BLANKET
Redarc Sun Solar Blanket
– ACCESSORY –
240W SOLAR BLANKET
Redarc Sun Solar Blanket
– ACCESSORY –
300W SOLAR BLANKET
Redarc Sun Solar Blanket
– ACCESSORY –
PATRIOT CAMPING GEAR
REAR WHEEL RUBBISH BIN
50L capacity / PVC
– CAMPING GEAR –
EN SUITE SHOWER TENT
Unpacked Dimentions 120x240x200cm
– CAMPING GEAR –
MEDIA DISPLAY DEVICE HOLDER
Velcro tabs to secure to tent pole
– CAMPING GEAR –
CLEAR STORAGE BAG
L (38cm) / W (35cm) / H (15cm)
– CAMPING GEAR –
*HEXOCORE™ Awning Test Results Disclaimer: Note that references towards the shade structures may not provide protection against reflected or scattered solar ultraviolet radiation. The UPF rating may be reduced when the material is incorporated into a shade product depending on factors that include the design of the product, the distance from the people being protected and the positioning of the product in relation to the people and the sun.
**Recovery point ratings are dependant on the Load Angle used and the recovery method. Please refer to the Recovery Point safety sticker on each Patriot Camper to ensure safe use of these points. Incorrect use may result in damage, injury or death. Only use rated recovery equipment using both recovery points. It is recommended to complete recovery training prior to use. Points to be used together for recovery, not independently.
*Water Tank Capacity may vary
Note: Images are for illustrative purposes only. Features and Options of each model will vary slightly in different locations due to differing compliance regulations and distribution requirements. Please contact your local dealer for further information.
